The Xenomech Analytical Ferrograph A10 is designed for accurate and reliable prediction of machine wear and potential lubricant failure. Operating on a 220 V power supply, it can generate a magnetic flux density of up to 1.5 T, enabling smooth and efficient separation of wear particles.
The instrument features both automatic and manual cleaning modes, ensuring easy and hassle-free maintenance. An integrated OLED display provides immediate results along with live testing updates, enhancing operational efficiency and user experience.
The Xenomech Analytical Ferrograph is widely used across multiple industries, including the transportation sector, iron and steel industry, electric power industry, and naval defense applications, making it a reliable solution for condition monitoring and predictive maintenance.
Availability: In Stock
| Parameter | Specification |
|---|---|
| Brand | Xenomech |
| Product Name | Analytical Ferrograph |
| Model | A10 |
| Wear Particle Measurement Range | 0 µm to 800 µm |
| Injection Method | Micro pump pressure type, automatic sampling |
| Cleaning Method | Automatic cleaning and manual cleaning |
| Maximum Magnetic Flux Density | 1.5 T (±0.1 T) |
| Maximum Magnetic Field Gradient | < 0.5 T/mm |
| Magnetic Field | High-gradient magnetic field |
| Spectrum-Making Channel | Dual-channel synchronous spectroscopy |
| Plate Inclination | 1° to 5° |
| Oil Sample Transfer Speed | 10–30 ml/h |
| Cleaning Agent Flow Rate | 10–30 ml/h |
| Measurement Resolution | 1 µm |
| Sample Size (Single Analysis) | 1 ml |
| Oil Delivery Pipe Size | Outer Ø 2.6 mm, Inner Ø 1.8 mm |
| Ferrographic Substrate Size | 60 × 24 × 0.17 mm |
| Display Screen | 1.54-inch OLED display |
| Power Supply | 220 V |
| Dimensions | 395 × 355 × 335 mm |
| Weight | Approx. 14 kg |
