The Xenomech Glass Tank Bioreactor A10 is a 5-liter laboratory bioreactor designed for precise and efficient microbial and cell culture operations. It operates at a sterilization temperature of 121°C and features a mechanical stirrer with stainless-steel shaft for stable and accurate mixing.
Constructed from SUS316 stainless steel and borosilicate glass, the bioreactor offers durability, chemical resistance, and visual monitoring. It includes an exhaust system with tail gas discharge condenser, multiple sensor interfaces, integrated foam control, and a touch interface for intuitive operation. Its PID automatic control system ensures precise regulation of temperature, pH, dissolved oxygen, and mixing speed, making it ideal for biotechnology, pharmaceutical, and research laboratories.
Availability: In Stock
| Parameter | Specification |
|---|---|
| Brand | Xenomech |
| Product Name | Glass Tank Bioreactor |
| Model | A10 |
| Capacity | 5 L |
| Maximum Working Volume | 70% |
| Sterilization Temperature | 121 °C |
| Sterilization Temperature Range | 100–130 °C |
| Maximum Sterilization Temperature | 131 °C |
| Working Pressure | 0.15 MPa |
| Design Pressure | 0.2 MPa |
| Sterilization Time | 30 min at 121 °C |
| Tank Material | SUS316 stainless steel + borosilicate glass |
| Diameter-to-Height Ratio | ~1:2 |
| Surface Treatment | Internal & external mirror polishing |
| Internal Surface Accuracy | <0.4 µm |
| External Surface Accuracy | <0.6 µm |
| Maximum Ventilation Rate | Up to 2 VVM |
| Air Filter Element Accuracy | 0.2 µm |
| Flow Control | Rotameter manual control, 0–8 L/min |
| Mixing Control | PID automatic control, stepless speed regulation |
| Mixing Speed Range | 50–1000 RPM |
| Mixing Control Accuracy | ±0.5% |
| Temperature Sensor | German Pt100 electrode |
| Sensor Interfaces | 1 flame ring inoculation, 1 pH, 1 DO, 1 temperature, 2 spare ports |
| Foam Control | Integrated foam sensor with peristaltic pump, 10–100,000 Ω accuracy |
| Cooling Water Temp Range | +5°C to 65°C ±0.2°C |
| Display Temperature Range | 0–150°C ±0.1°C |
| pH Display Range | 0.00–14.00 ±0.01 |
| pH Control Range | 2.00–12.00 ±0.01, PID intelligent control |
| DO Electrode | Swiss imported, shielded wire detection |
| DO Control Range | 0–150% ±3% |
| DO Resolution | 0.1% |
| Power Supply | 220 V / 50 Hz |
| Dimensions (L × W × H) | 850 × 700 × 980 mm |
| Net Weight | 88 kg |
| Gross Weight | 97 kg |
